Form Factor
1U rack-mount server
CPU
Dual Intel Xeon 6 Scalable processors (up to 144 cores each)
Memory
Up to 4TB DDR5-5600 (16x DIMM slots)
Expansion PCIe
2x PCIe 5.0 x16 slots (for NVIDIA GPUs or Intel Gaudi 3 AI accelerators), 1x PCIe 5.0 x8 slot
HD
Up to 12x 2.5” NVMe/SATA hot-swap bays, optional 2x M.2 slots
Network Interfaces
- Supports NVIDIA ConnectX-7 NICs (200GbE/400GbE)
- 2x 10GbE LAN ports for AI networking
Performance Features
- Designed for scalable AI operations, supporting AI inference and training workloads
- Features Intel Xeon 6 processors with Data Center Modular Hardware System (DC-MHS) architecture for scalability and maintenance
- Supports NVIDIA GPUs (e.g., H100) or Intel Gaudi 3 AI accelerators for generative AI inferencing and fine-tuning
Management
- ASUS Control Center (ACC) for server management
- Integrates with NVIDIA AI Enterprise and Intel AI software frameworks
Power Supply
- Redundant, hot-swappable 1600W power supplies
- Air-cooled design for AI data centers
