Form Factor
2U rack server
Processor
Two 4th/5th Gen Intel® Xeon® Scalable (up to 64 cores) or AMD EPYC™ 9004 (up to 96 cores)
GPU
- Up to 4x NVIDIA H100/A100 PCIe (700W TDP)
- Support for AMD Instinct MI300X
- PCIe 5.0 ready for future GPUs
Memory
- DIMM Speed: Up to 5600 MT/s (DDR5)
- Memory Type: RDIMM/3DS RDIMM
- Module Slots: 32 DIMM slots
- Max Capacity: 6TB
Storage
- Front Bay: Up to 32x NVMe U.2/EDSFF (max 491TB)
- Boot Options: Dual M.2 SATA/NVMe (BOSS-N2)
- Storage Controllers: HPE Smart Array E208i-p (HW RAID)
Network Options
- 1x OCP 3.0 (up to 200Gbps)
- 2x 25GbE LOM (embedded)
Ports
- Front: 1x USB 3.2, 1x iLO6 management
- Rear: 2x USB 3.2, 1x VGA, 1x serial
Management
- HPE iLO6 with Redfish API
- HPE OneView integration
- HPE GreenLake monitoring
Security
- Silicon Root of Trust
- Secure Boot + Measured Boot
- Firmware TPM (fTPM)
- HPE Trusted Supply Chain
PSU
- 2400W Titanium (200-240V AC)
- N+1 Redundancy
- Liquid-cooling ready
Dimensions
- Height: 3.46" (87.8mm)
- Width: 17.6" (447mm)
- Depth: 29.1" (739mm)
- Weight: ~80 lbs (36.3kg) base
